Low Voltage Stacked ESS

UN38.3, CE, IEC62619 and other security performance certification.

Play Video

Datasheet

User Manual

Join Xinrex's Elite Partner Network.

FEATURES

From 5.12kWh To 30.6kWh

Match The Voltage Automatically

IP65. Support Outdoor Usage

Wireless Connection / Easy To Install / Save Space

LFP Cells. Cobalt Free

Match With Mainstream Inverter Brands

SPECIFICATION

Item	LV M05	LV M10	LV M15	LV M20	LV M25	LV M30
Module Number	1	2	3	4	5	6
Nominal Capacity	100Ah	200Ah	300Ah	400Ah	500Ah	600Ah
Nominal Battery Energy	5.12kWh	10.2kWh	15.3kWh	20.4kWh	25.5kWh	30.6kWh
Max. Discharge Power	5kW	10kW	10kW	10kW	10kW	10kW
Max. Charge Power	5kW	10kW	10kW	10kW	10kW	10kW
Dimension[WDH]	700370441	700370609	700370777	700370945	7003701113	7003701281
NetWeight	73.7kg	123.2kg	172.7kg	222.2kg	271.7kg	321.2kg
Temp.Range	0℃ ~ 50℃（Charge） -20℃ ~ 55℃ （Discharge）
Warranty Letter	Yes
Ingress Protection	IP65
Color	White
Alarms	Over Charge / Over Discharge / Over Current / Over Temperature / Short Circuit
Pros	Can be used in both off-grid and hybrid set ups, compact design
Battery Module Type	Low Voltage
Module Connection Method	Parallel
Compatible Inverters	GoodWe/Deye/Megarevo/Growatt/Lux Power/TBB/Victron/Srne/Must/Senergy/Voltronic/Aptai/Sofar/Sma,etc
