Quickly raises battery temperature by 20°C+ in cold conditions
97.8% conversion and 95% battery-to-AC efficiency significantly cut energy waste and costs.
Multi-level protection meets global standards
LCD + Wi-Fi enable real-time tracking and remote fault alerts for proactive oversight.
Power switchover in <20ms (capacitive) and <10ms (resistive) ensures stable operation during fluctuations.
Runs below 40dB
| 电池数据 | |
| 电池材料 | LiFePO4 |
| 标称容量 | 300Ah |
| 额定电压 | 51.2V |
| 能量 | 15.36KWh> |
| 通信方式 | CAN、RS485、RS232 |
| 充电截止电压 | 58.4V |
| 放电截止电压 | 44V |
| 最大充电电流 | 100A |
| 最大放电电流 | 100A |
| 循环寿命 | ≥6,000 Times |
| 内部阻抗 | ≤20mΩ |
| 环境温度 | -20℃~55℃ |
| 交流输入 | |
| 主要拓扑结构 | L+N+PE |
| 额定电压 | 230VAC |
| 交流输出 | |
| 输出电压波形 | Pure sine wave |
| 输出电压 | 230VAC |
| 标称输出功率 | 5KW |
| 通用参数 | |
| IP保护等级 | IP65 |
| 工作温度范围 | -20℃~55℃ |
| 环境湿度 | 5-95%(No condensation ） |
| 质量保证 | 5 Years for battery cells and 2 years for inverter boards |
| 工作高度 | <2000m> |
| 冷却 | Intelligent air cooling |
| 尺寸 | 680×300×1630(mm) |
| 重量 | 140kg |
| 噪音 | <50db> |
